Kyocera Ecosys M6526cdn

2PV/2PW
1-5-36
(5) Detaching and refitting the FAX control PWB (4 in 1 model (with FAX) only)
Procedure
1. Remove the IF cover (see page 1-5-3).
2. Remove two screws and then remove
the FAX control PWB.
3. Check or replace the FAX control PWB
and refit all the removed parts.
Figure 1-5-54
Screw
FAX control PWB
Screw
