Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
2-4-13
Adjusting the scanning position for originals from the DP (alternative command for the maintenance
mode U068)
Description
Adjusts the position for scanning originals from the DP. Performs the test copy at the four scanning positions
after adjusting.
Purpose
Used when the image fogging occurs because the scanning position is not proper when the DP is used. Exe-
cute KCFG “EESS”,4, 107, 1, “#1”; command to adjust the timing of DP leading edge when the scanning posi-
tion is changed.
Example: DP READ set to 15, BLACK LINE set to 3
!R! KCFG “SCAN”,9,1,15; KCFG “SCAN”,9,2,3;EXIT;
Format !R! KCFG “SCAN”,9, #1,#2;EXIT;
Parameter #1 1: DP READ Starting position adjustment for scanning originals
2: BLACK LINE Scanning position for the test copy originals
#2 #1=1: Adjustable range: -33 to 33 (in 0.086mm increment) (0: default)
#1=2: Adjustable range: 0 to 3 (in 0.22mm increment) (0: default)

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
