2PV/2PW-3
1-3-45
U425 Set Target
Description
Enters the lab values that is indicated on the back of the chart (P/N: 302NM94340) used for
adjustment.
Purpose
Performs data input in order to correct for differences in originals during automatic adjustment.
Method
1. Press the start key.
2. Select the item to be set
Method: Table
1. Press the start key.
2. Select the item to be set..
3. Select the item to be set.
4. Enters the value that is indicated on the back of the chart using the cursor right/left keys or
numeric keys.
5. Press the start key. The value is set.
Item No. Description
Display Description
Table Setting the value of the table adjustment.
DP Setting the value of DP adjustment.
Display Description
White Setting the white patch for the original for adjustment
Black Setting the black patch for the original for adjustment
Gray1 Setting the Gray1 patch for the original for adjustment
Gray2 Setting the Gray2 patch for the original for adjustment
Gray3 Setting the Gray3 patch for the original for adjustment
C Setting the cyan patch for the original for adjustment
M Setting the magenta patch for the original for adjustment
Y Setting the yellow patch for the original for adjustment
R Setting the red patch for the original for adjustment
G Setting the green patch for the original for adjustment
B Setting the blue patch for the original for adjustment
Adjust Original Setting the main and auxiliary scanning directions
Display Description Setting range Initial setting
L Setting the L value 0.0 to 100.0 93.6/10.6/76.2/25.2/51.3
72.6/48.1/86.2/46.7/67.8/38.8
a Setting the a value -200.0 to 200.0 0.9/-0.2/-0.2/-0.2/-0.3
-32.8/69.9/-18.6/54.2/-51.3/25.3
b Setting the b value -200.0 to 200.0 -0.4/-0.7/1.2/-0.2/0.3
-11.5/-6.1/81.7/38.6/48.9/-22.8
