Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
2-1-8
Figure 2-1-8 Drum section block diagram
DRRPWB
EPWB
HVPWB
DRPWB-K
CL-K
ERASECDR ERASEMDR ERASEKDR EECLK EEDATA ERASEYDR
YC34-2 YC34-4 YC34-6 YC34-8
YC34-10 YC34-12
YC1-2 YC1-4 YC1-6 YC1-8 YC1-10 YC1-12
EECLK ERASEKDR
ERASEKDR
ERASEMDR
EEDATA DA0 DA1 EEDATA DA0 DA1
YC2-2 YC2-3 YC2-4 YC2-7 YC2-8 YC3-2 YC3-3 YC3-4 YC3-7 YC3-8
CL-M
EEPROM
DRPWB-M
EECLK ERASEMDR
EEPROM
ERASECDR
EEDATA DA0 DA1
YC4-2 YC4-3 YC4-4 YC4-7 YC4-8
CL-C
DRPWB-C
EECLK ERASECDR
EEPROM
ERASEYDR
EEDATA DA0 DA1
YC5-2 YC5-3 YC5-4 YC5-7 YC5-8
Main chager high voltage Y Main chager high voltage C Main chager high voltage M Main chager high voltage K
Drum
unit Y
Drum
unit C
Drum
unit M
Drum
unit K
CL-Y
DRPWB-Y
EECLK ERASEYDR
EEPROM
MOTRDYN
YC13-2
SPEEDSEL
YC13-3
MOTCLK
MOTEN
YC13-4
YC13-5
6
5
4
3
DRM
