Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-3-33
U253 Switching between double and single counts
Description
Switches the count system for the total counter and other counters.
Purpose
Used to select, according to the preference of the user (copy service provider), if folio size paper
is to be counted as one sheet (single count) or two sheets (double count).
Setting
1. Press the start key.
2. Select the item using the cursor up/down keys.
3. Press the start key.
4. Select the count system using the cursor up/down keys.
* : Initial setting: DBL Count(Folio)
5. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U260 Selecting the timing for copy counting
Description
Changes the copy count timing for the total counter and other counters.
Purpose
To be set according to user request.
Setting
1. Press the start key.
2. Select the copy count timing using the cursor up/down keys.
* : Initial setting:
Eject
3. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Color Count system of color mode
B/W Count system of black/white mode
Display Description
SGL Count(All) Single count for all size paper
DBL Count(Folio) Double count for Folio size or larger
Display Description
Feed When secondary paper feed starts
Eject When the paper is ejected
