2PV/2PW-3
1-1-2
Photoconductor OPC drum (diameter 30 mm)
Image write system Semiconductor laser
Charging system Charger roller
Developing system
Touch down developing system
Developer: 2-component
Toner replenishing: Automatic from the toner container
Transfer system
Primary: Transfer belt
Secondary: Transfer roller
Separation system Small diameter separation
Cleaning system Drum: Counter blade
Charge erasing system Exposure by cleaning lamp (LED)
Fusing system
Heat and pressure fusing with the heat roller and the press roller
Heat source: halogen heater
Abnormally high temperature protection devices: thermostat
CPU PowerPC465S (667MHz)
Main
memory
Standard 1 GB
Maximum 2 GB
Interface
Standard
USB interface connector: 1 (USB Hi-speed)
USB host: 2
Network interface: 1 (10BASE-T/100BASE-TX/1000BASE-T)
Option
eKUIO slot: 1
Resolution 600 × 600 dpi
Operating
environment
Temperature 10 to 32.5 °C/50 to 90.5 °F
Humidity 15 to 80% RH
Altitude 2,500 m/8,202 ft or less
Brightness 1,500 lux or less
Dimensions (W × D × H)
514 × 550 × 580 mm
20 1/4 × 21 5/8 × 22 13/16”
Weight
36.5 kg / 80.3 lb
(with toner container)
Space required (W × D)
514 × 1020 mm (using MP tray)
20 1/4 × 40 3/16” (using MP tray)
Rated input
120 V AC, 60 Hz, more than 8.9 A
220 - 240 V AC, 50/60 Hz, more than 4.7 A
Options
Paper feeder × 2, Expanded memory, Card authentication kit, Card reader
holder, USB keyboard, SSD
Item
Specifications
3 in 1 model (without FAX) 4 in 1 model (with FAX)
