Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-4-39
(22)
DP switchback
solenoid does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
DP switchback solenoid and DP drive PWB (YC5)
DP drive PWB (YC8) and main PWB (YC32)
2. Defective solenoid. Replace the DP switchback solenoid.
3. Defective PWB. Replace the DP drive PWB or main PWB and check for
correct operation (see page 1-5-87, 1-5-30).
(23)
An original jams
when the main
power switch is
turned on.
1. A piece of paper torn
from an original is
caught around the
DP timing sensor.
Check visually and remove it, if any.
2. Defective DP timing
sensor.
Replace the DP timing sensor.
(24)
A message indicat-
ing cover open is
displayed when the
DP top cover is
closed.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
DP open/close sensor and DP drive PWB (YC2)
DP drive PWB (YC8) and main PWB (YC32)
2. Defective DP open/
close sensor.
Replace the DP open/close sensor.
Problem Causes Check procedures/corrective measures

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
