Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-4-41
(7)
No primary original
feed.
Check if the surfaces of the following pul-
leys are dirty with paper powder.
DP forwarding pulley
DP feed pulley
Clean with isopropyl alcohol.
Check if the following pulleys is
deformed.
DP forwarding pulley
DP feed pulley
Check visually and replace any
deformed (see page 1-5-82).
(8)
Multiple sheets of orig-
inal are fed.
Original is not correctly set. Set the original correctly.
Check if the DP separation pad is worn. Replace the DP separation pad if it is
worn (see page 1-5-86).
(9)
Originals jam.
Originals outside the specifications are
used.
Use only originals conforming to the
specifications.
Check if the surfaces of the following pul-
leys are dirty with paper powder.
DP forwarding pulley
DP feed pulley
Clean with isopropyl alcohol.
Check if the contact between the convey-
ing roller and conveying pulley is correct.
Check visually and remedy if necessary.
Check if the contact between the eject
roller and eject pulley is correct.
Check visually and remedy if necessary.
Check if the contact between the switch-
back roller and switchback pulley is cor-
rect.
Check visually and remedy if necessary.
Problem Causes/check procedures Corrective measures

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
