Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-5-28
3. Remove three screws and then remove
the engine PWB.
4. Check or replace the engine PWB and
refit all the removed parts.
*: To replace the engine PWB, remove the
EEPROM (U1) from the old engine PWB
and mount it to the new engine PWB.
Figure 1-5-40
Screw
EEPROM (U1)
Engine PWB
Screw
Screw
