2PV/2PW
1-5-39
7.
Remove five screws and then remove
drum/deve
loping drive
unit.
8.
Check or replace the drum/d
eveloping
drive unit and refit all the removed
par
ts.
Figure 1-5-59
Drum/Developing
drive unit
Screw
Screw
Screw
Screw
Screw
228
