Kyocera Ecosys M6526cdn

2PV/2PW-2
1-5-55
9. Remove the screw.
10. Release four hooks. Slide the right rear
cover backward and then remove it.
Figure 1-5-85
11. Open the memory cover and then
remove it.
Figure 1-5-86
Right rear
cover
Right rear
cover
Screw
Hook
Hook
Hook
Hook
Memory cover
