Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
1-2-5
5. Remove tape A and pad.
6. Move the lock lever to the position of
release.
* : When turning on power if the lock lever
is not released, the error message is
displayed.
7. Remove tape B.
8. Close the DP.
Figure 1-2-6
9. Remove two tapes.
Figure 1-2-7
Tape B
DP
Tape A
Pad
Lock lever
Tape
Tape

Kyocera Ecosys M6526cdn Specifications

General

Brand	Kyocera
Model	Ecosys M6526cdn
Category	All in One Printer
Language	English
