Kyocera Ecosys M6526cdn Service Manual

2PV/2PW
2-3-2
Connector Pin Signal I/O Voltage Description
YC101 1 LIVE I 120 V AC
220-240 V AC
AC power input
Connected to
AC inlet and
main power
switch
2 NEUTRAL I 120 V AC
220-240 V AC
AC power input
YC102 1 NEUTRAL O 120 V AC/0 V
220-240 V AC/0 V
FH: On/Off
Connected to
fuser heater
2 LIVE O 120 V AC
220-240 V AC
AC power to FH
YC103 1 +24V1 O 24 V DC 24 V DC power to RYPWB
Connected to
relay PWB
2 GND - - Ground
3 GND - - Ground
4 GND - - Ground
5 GND - - Ground
6 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
7 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
8 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
9 +24V2 O 24 V DC 24 V DC power to RYPWB (via ILSW)
10 PSSLEEPN I 0/3.3 V DC Sleep mode signal: On/Off
11 ZCROSS O 0/3.3 V DC (pulse) Zero-cross signal
12 RELAY
I
0/3.3 V DC Power relay signal: On/Off
13 HEATRE1 I 0/3.3 V DC FH: On/Off
YC104 1 +24V1 O 24 V DC 24 V DC power to ILSW
Connected to
interlock
switch
2N.C -- Not used
3 +24V2 I 24 V DC 24 V DC power from ILSW
YC105 1 +24V1 O 24 V DC 24 V DC power to MPWB
Connected to
main PWB
2 GND - - Ground
3 GND - - Ground
4 +5V1 O 5 V DC 5 V DC power to MPWB

Kyocera Ecosys M6526cdn Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Duplex Printing	Yes
Paper Capacity	250 sheets
Functions	Print, Copy, Scan, Fax
Fax Speed	33.6 kbps
Mobile Printing Support	Yes
Paper Output Capacity	150 sheets
Max Paper Size	A4
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Warm-up Time	29 seconds
Duty Cycle	50, 000 pages per month
Recommended Monthly Print Volume	Up to 3, 000 pages
First Copy Out Time	10 seconds
Zoom Range	25% - 400%
Scan to	Email, FTP, SMB, USB
Fax Resolution	300 x 300 dpi
Memory	512 MB
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
