2PV/2PW-3
1-3-43
U411 Method: Table
To Automaticary enter the target value : Usually, it adjusts here.
1. Set a specified original (P/N: 302NM94340) on the platen.
2. Enter maintenance item U411.
3. Select [Target].
4. Select [Auto] and press the start key.
5. Select [Table].
6. Press the start key. Auto adjustment starts.
To manually enter the target value : When adjustment is automatically impossible.
1. Enter the target values which are shown on the specified original (P/N: 302NM94340) exe-
cuting maintenance item U425.
2. Set a specified original (P/N: 302NM94340) on the platen.
3. Enter maintenance item U411.
4. Select [Target].
5. Select [U425] and press the start key.
6. Select [Table].
7. Press the start key. Auto adjustment starts.
Method: DP
1. Set a specified original (P/N: 302NM94330) on the DP face up.
2. Enter maintenance item U411.
3. Select [DP].
4. Press the start key. Auto adjustment starts.
* : When automatic adjustment has normally completed, [OK] is displayed. If a problem
occurs during auto adjustment, error code is displayed and operation stops. Should this
happen, determine the details of the problem and repeat the procedure from the begin-
ning.
Error Codes
Item No. Description
Codes Description
00 Automatic adjustment success
01 Black band detection error (scanner auxiliary scanning direction leading
edge skew )
02 Black band detection error (scanner main scanning direction far end skew)
03 Black band detection error (scanner main scanning direction near end
skew)
03 Black band detection error (scanner auxiliary scanning direction trailing
edge skew)
04 Black band is not detected (scanner auxiliary scanning direction leading
edge)
05 Black band is not detected (scanner main scanning direction far end)
To Next Page
