4-13
Printing from PC > Printing from PC
Banner printing
When a document length from 470.1 mm (18.51") to a maximum of 915.0 mm (36.03") is specified for printing,
the print job is treated as banner printing.
Follow the steps below to set banner paper in the printer driver.
1
Display the screen.
Click [File] and select [Print] in the application.
2
Configure the settings.
1 Select the machine from the "Name" menu and click the [Properties] button.
2 Select the [Basic] tab.
3 Click the [Page Size...] button.
Max. number of sheets 1 sheet (multi purpose tray)
Paper width 210 mm to 216 (8.5") mm
Paper length 470.1 mm to 915 mm (18.51" to 36.03")
Paper weight 136 to 163 g/m
2
Paper type Heavy 2
To Next Page
