Installing and Setting up the Machine > Network Setup
Configuring the Wireless Network
When the Wireless Network Interface Kit (IB-37/IB-38/IB-51) is installed on the machine and the connection
settings are configured, it is possible to print or send in a wireless network (wireless LAN) environment. The
configuration methods are as follows:
Wired Connection with LAN Cable Using Wi-Fi Setup Tool
To send the Wi-Fi settings configured in the Wi-Fi Setup Tool to the machine, connect the computer or handheld
device with the machine locally. To use a wired LAN cable directly connected to the machine, the Auto-IP (Link-
local) address will be assigned to the machine and the computer. This machine applies Auto-IP as the default
settings.
Configuration Method Description Reference Page
Configuring the Connection
from the Operation Panel on
This Machine
Use Wi-Fi Settings to configure the network in details
from System menu.
Wi-Fi Settings (page 8-9)
Setting the Connection by
Using the Wi-Fi Setup Tool
This is a tool that can be downloaded from our website.
You can configure the connection according to the
instructions provided by the wizard.
Wired Connection with LAN
Cable Using Wi-Fi Setup Tool
(page 2-20)
Configuring Connections on
the Web Page
For the IB-37/IB-38, the connection can be set from the
Command Center RX.
Command Center RX User
Guide
For the IB-51, the connection can be set on the
dedicated Web page.
IB-51 Operation Guide
Setting the Connection by
Using the Setup Utility of
IB-51
This is the setup tool included in the CD of IB-51. You
can use it on both Windows and Mac OS.
IB-51 Operation Guide
When you want to switch to the network interface other than Wired (default) after installing an optional
Network Interface Kit (IB-50) and a Wireless Network Interface Kit (IB-37/IB-38/IB-51), select the desired setting
on "Primary Network (Client)".
Primary Network (page 8-21)
Configure the settings on the operation panel if your computer supports WPS.
Wi-Fi Settings (page 8-9)
