Labconco Logic+ A2 User Manual

186
4. For the 5-ft and 6-ft IV Bars only, insert the center support brace on the IV Bar.
Position the center support as shown in Figure 20-2 while completing Step 5.
5. Slide the other bracket onto the IV bar, and fasten it to the opposite sidewall as
done in Step 3.
6. For the 5-ft and 6-ft IV Bars only, fasten the center support brace onto the back
wall with the two screws provided in the kit.
7. Secure each of the brackets by tightening all of the fasteners.
Figure 20-2
Center
Support
