Acceptance Criteria
Inflow Volume shall be in the range specified in Table 10-7 column “Inflow Volume
Range”.
Type
A2 & B2
Cabinet
Width
Sash
Height
Inflow
Average
1
Sash Open Area
Inflow
Volume
Inflow Volume Range
inches
FPM (m/s)
ft
2
m
2
CFM
CFM
m
3
/hr
3-foot
8
105
2.03
0.19
213
203-223
345-379
9
105
2.28
0.21
240
228-251
387-426
10
105
2.53
0.24
266
253-278
430-472
4-foot
8
105
2.69
0.25
283
269-296
457-503
9
105
3.03
0.28
318
303-333
515-566
10
105
3.37
0.31
354
337-371
573-630
12
105
4.04
0.38
424
404-444
686-754
5-foot
8
105
3.36
0.31
353
336-370
571-629
9
105
3.78
0.35
397
378-416
642-707
10
105
4.20
0.39
441
420-462
714-785
12
105
5.05
0.47
530
505-555
858-943
6-foot
8
105
4.03
0.37
423
403-443
685-753
9
105
4.53
0.42
476
453-498
770-846
10
105
5.03
0.47
529
503-553
855-940
12
105
6.06
0.56
636
606-666
1030-1132
Type C1
Cabinet
Width
Sash
Height
Inflow
Average
1
Sash Open Area
Inflow
Volume
Inflow Volume Range
inches
FPM (m/s)
ft
2
m
2
CFM
CFM
m
3
/hr
4-foot
8
105
2.69
0.25
283
269-296
457-503
10
105
3.37
0.31
354
337-371
573-630
6-foot
8
105
4.03
0.37
423
403-443
685-753
10
105
5.03
0.47
529
503-553
855-940
1. Tolerance for Average Inflow Velocity = +/- 5 FPM (+/- 0.03 m/s)
Table 10-7
