Labconco Logic+ A2 - Type A2 (12-Inch Sash) and Type C1

46
Type A2 (12-inch sash) and Type C1
1. On the Supply Blower Speed screen, press [OK/MUTE].
2. Use [UP] or [DOWN] to select one of the three Filter Life options displayed,
press [OK/MUTE].
3. On the Exhaust Blower Speed screen, press [OK/MUTE].
4. Use [UP] or [DOWN] to select one of the three Filter Life options displayed,
press [OK/MUTE].
Note: On dual blower models, each filter has a separate Life Gauge for percentage of
filter remaining. The lower of the two Filter Life percentages is displayed on the Home
Screen.
58
CURRENT RPM = 1217
AVERAGE RPM = 1219
‘OK’ TO CONTINUE
‘OK’ displayed when blower speed stabilizes
NEW FILTER
SAME FILTER
SET FILTER LIFE
[OK/MUTE]
SUPPLY
SUPPLY
51
CURRENT RPM = 1193
AVERAGE RPM = 1075
‘OK’ TO CONTINUE
‘OK’ displayed when blower speed stabilizes
NEW FILTER
SAME FILTER
SET FILTER LIFE
[OK/MUTE]
EXHAUST
EXHAUST
