Labconco Logic+ A2 User Manual

93
QuickChart – Type B2
Type B2 Cabinet Width
4-ft
6-ft
Sash Opening (inches)
8
8
Starting Serial #
1905_
1905_
Downflow Data
Nominal Avg. Downflow (FPM)
55+/-5
55+/-5
Grid points (rows x columns)
24 (3x8)
36(3x12)
Grid distance from back & sides
6.0
6.0
Distance between rows
5.75
5.75
Distance between columns
5.21
5.50
Inflow/Exhaust Data
Nominal Average Inflow (FPM)
105+/-5
105+/-5
Sash Open Area (Sq. Ft)
2.69
4.03
Nominal Avg. Inflow Vol. (CFM)
283
423
Avg. Inflow Vol. Range (CFM)
269-296
403-443
Secondary Inflow Data
Sash Opening Template
1
4+
6+
Sensor distance (inches)
2
3.25
4
# of Test points
8
12
Avg. Inflow Vel. Range (FPM)
269-296
220-242
Correction Factor (CF)
1
1.83
Corrected Inflow Volume (CIV)
(Avg. velocity x CF)
269-296
403-443
Supply HEPA Filter Leak Test Data
Air Displacement (CFM)
445
665
Laskin Nozzles needed
1
1
Theoretical aerosol conc. (ug/l)
3
30
15
Actual aerosol conc. (ug/l)
4
20
12
Supply HEPA Data
Labconco P/N
3838401
3838403
Width x Depth x Height (in.)
5
48x18x3.06
72x18x3.06
Performance (CFM)
445
665
Pressure Drop (in. H
2
O)
.5+/-.1”
.38-.5”
Exhaust HEPA Filter Leak Test Data
Air Displacement (CFM)
723
1083
Laskin Nozzles needed
2
2
Theoretical aerosol conc. (ug/l)
3
38
25
Actual aerosol conc. (ug/l)
4
21
17
Exhaust HEPA Data
Labconco P/N
3438501
3438503
Width x Depth x Height (in.)
5
26x18x8.08
48x18x8.08
Performance (CFM)
720
1100
Performance (in. H
2
O)
.48+/-.07”
.37+/-.07”
LED Lamp Data (2 each)
7
Labconco P/N
1297504
1297506
LED Lamps (Direct Drive)
15T8-48
32T8-72
Color (
o
K)
4000
4000
Lumens
1850
3200
Glass Type
Frosted
Frosted
Remote Exhaust System Data
DIM
8
Total Exhaust Airflow (CFM)
9
723
1083
Traverse Total Exhaust Airflow (CFM)
10
852
1265
Recommended Duct Vacuum (in. H
2
O)
11
1.8
2.2
Exhaust (Inflow) Alarm Data
Inflow Alarm Set Point (CFM)
210 +/-5
315 +/-5
Volume of Hull
Cubic Feet
39
58
See footnotes on following page
