5: Factory Test Report
The factory test report is a valuable reference for the product’s airflows and blower
setting(s), as well as information about the HEPA filters, and accessories that may be
factory installed.
Test Report Location
The test report is located on the blower/plenum cover, which is behind the front dress
panel. See Figure 5-1. The Dress Panel Screws must be removed and the Dress Panel
lifted off to reach the test report.
Dress Panel
Primary
Serial Tag
Secondary
Serial Tag
Data Plate
Dress Panel
Screw
Dress Panel
Screw
Factory
Test
Report
Wiring
Diagram
Behind
Dress
Panel
Figure 5-1
