Table 2 - Control Station Loads
Example:
Suppose we had a network with the following equipment:
• D4200 LCD Stations
• D4200 Entry Stations
• Remote IR Station
• Powered from an a-2000 24 Cabinet with a Standard Power
Supply
Use these quantities along with the Load Rating verification formula
(Figure 1) to do the math and verify that the combined unit input load
does not exceed the maximum input Unit Load Available.
Station Type Unit Load
(per
station)
Station Type Unit
Load
(per
station)
D4200 LCD 5 D8000 Key switch 1
D4200 Entry
(Button)
2 D8000 Port (LumaEdit,
A/V, etc.)
2
D4200 Combine/
Closure (Simple)
2 D8000 Combine/Closure
(Advanced)
11
D4200 Remote I/R 2 Sapphire LCD 3
Luma-Net Hub 6 Sapphire Slider 2
D8000 LCD 3 Sapphire Button
Stations
2
D8000 Entry
(Button)
2
D8000 Slider 2
