34 is less than the 47 available so all the components CAN BE
wired
on a single run from the a-2000 24 Channel cabinet without an
additional external power supply.
Power Wire Run Length
The maximum total run length of each segment is a function of the
total number of unit loads. A run becomes to long with the voltage
drop due to wire size and run length increase to a point where the
station does not have sufficient voltage to operate. The maximum run
length, in feet based on the total number of unit loads is shown
below:
Quantity Unit Loads
D4200 LCD
Stations
4x5 =20
+
D4200 Entry
Stations
6x2 =12
+
Remote IR
Station
1x2 =2
Total 34
