Scheduling
The D4200 is already programmed to accept up to 64 possible
Events, numbered E01 through E64. The default values are 12:00a
(12:00 am), NONE (no Scene), and SMTWTFS (all days of the week).
To create Events you must edit the schedule and change the default
values (see
Editing the Schedule ).
The types of events that may be scheduled are:
• Scenes 1 to 16, MAX or OFF
• Sequencer ON / OFF / RESUME, or GOTO <step> (1 to 64)
• Photo CELL ON
Editing the Schedule
To simplify the process, use the Scheduling table in Appendix A.
To edit the schedule:
Step 1: Press the Menu/Cancel button.
Step 2: Press the Up and Down buttons until EDIT
SCHEDULE? flashes on the LCD display.
Step 3: Press the Select/Save button.
The current Event number flashes.
Scheduled Events are displayed in the following format:
Step 4: Press the Up and Down buttons to scan
through the possible Events.
Step 5: Press the Select/Save button to select the Event you
want to edit.
The HOUR field flashes.
Step 6: Press the Up and Down buttons to change the
HOUR value.
Note: Press Clear to return the value to 12 .
E01: 07:12a S01
SMTWTFS
Scene
number
Scheduled
time
Event
number
Days of week
