Snapshotting light levels from an Entry
Station
You can also record/snapshot existing light levels to a scene location
from an entry station.
Step 1: Press and hold the Scene button (approximately 5
seconds) you wish to record/snapshot the level too, until
the button LED finally lights up.
Step 2: You are finished!
The default fade rate time for that scene will be 5
seconds. The only ways to record the scene with a
different fade rate is to record the scene from the Master
LCD station.
Changing the MAX and OFF Lighting Levels
Reducing the maximum output voltage to the lamps by 5% can
extend lamp life by double. This can be valuable when incandescent
lights are located where it is difficult to replace them.
To change the MAX lighting level:
Step 1: Press the MAX button.
The lighting levels fade to the current maximum level.
Step 2: Press the Zone Up or Down buttons beneath the
LCD display to adjust each zone to the maximum value
that you need.
Step 3: Press and hold the MAX button until the LCD display
shows FADETIME.
The fade time value flashes.
Step 4: Press the Up and Down buttons beneath the
LCD display to adjust the fade time.
Step 5: Press the Select/Save button to record the lighting levels
and fade time.
The LCD display shows
RECORDING SCENE TO S00
, with
S00
representing the Scene you chose.
