Table 7 - Flag Settings
1.1 - Setting the Dimmer Readback
When an intensity level on a dimmer changes using a Zone Up or
Down button, the changing levels shown on the LCD display and
the LED indicators are being fed back from the dimmer cabinet, and
the information you see represents what is actually happening in the
dimmer cabinet.
The normal setting for this function is OFF.
To set the Dimmer Readback:
Step 1: Access the Programming and Configuration Level menu
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up and Down buttons until MISC.
SETTINGS? flashes on the LCD display.
Step 4: Press the Select/Save button.
FLAGS flashes on the LCD display. This set of FLAGS can
be individually changed. The first one is the dimmer
“Readback.
If it is “lower” case the option is OFF.
If it is “UPPER” case the option is ON.
Function ON OFF
Default
Setting
Dimmer Readback: R
r OFF
Double Bump: B bOFF
LCD Backlight: L l ON
Time Master: T t OFF
Old Code Compatibility O o ON
IR Control I i ON
To Next Page
