For safety reasons, you might want to prevent certain lights from
turning completely off. Modifying the OFF lighting level changes the
minimum lighting levels.
To change the OFF lighting level:
Step 1: Press the OFF button.
The lighting levels fade to the current minimum level.
Step 2: Press the Zone Up or Down buttons to adjust each
zone to the minimum value that you need.
Step 3: Press and hold the OFF button until the LCD display shows
FADETIME.
The fade time value flashes.
Step 4: Press the Up and Down buttons beneath the
LCD display to adjust the fade time.
Step 5: Press the Select/Save button to record the lighting levels
and fade time.
The LCD display shows
RECORDING SCENE TO S00
, with
S00
representing the Scene you chose.
When the Double Bump feature is on, tapping the MAX or
OFF buttons twice overrides any high and low limits.
Therefore, if MAX and OFF are set at any levels other
than full bright and full off, the Double Bump feature
should be turned off.
Using the Optional Remote Control
If you have purchased the optional remote control, you can use it to
operate the Master RAISE/ LOWER, SCENE, MAX and OFF
buttons in the same manner as indicated above. The maximum range
for the remote control is approximately 30 feet.
