Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 7 of 80
Table 3 - Wire Size vs. Length of Runs - Power
Wiring
Terminating the Wiring
Luma-Net® III
Control Stations can be located up to 2000 ft. from the dimming
cabinet.
The 2000 ft. limitation is a RS485 digital communications
specification. The power supply pair must be sized
correctly for the control stations that are connected to
them.
14 AWG (Feet) 12 AWG (Feet) 10 AWG Feet)
10 Unit Loads 1904 3000 4800
20 Unit Loads 952 1500 2400
30 Unit Loads 634 1000 1600
40 Unit Loads 476 750 1200
50 Unit Loads 380 600 960
60 Unit Loads 317 500 800
70 Unit Loads 272 428 685
80 Unit Loads 238 375 600
90 Unit Loads 211 333 533
100 Unit Loads 190 300 480
110 Unit Loads 173 272 436
120 Unit Loads 158 250 400
