Step 8: Press the Up and Down buttons to change the
value.
“B” means the double bump is ON.
“b” means the double bump is OFF.
Step 9: Press the Left and Right buttons to select the
next Flag
or proceed to the next step until you do not want to make
any more changes to the remaining FLAGS.
Step 10: Press the Select/Save button to record the new setting.
Step 11: Exit the Programming and Configuration Level menu.
1.3 - Setting the LCD Backlight Time Out Flag
This flag allows the backlight on the LCD to turn off after 60 seconds
of no button presses on the D4200 station.
To enable this feature:
Step 1: Access the Programming and Configuration Level menu
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up and Down buttons until MISC.
SETTINGS? flashes on the LCD display.
Step 4: Press the Select/Save button.
FLAGS
flashes on the LCD display.
Step 5: Press the Select/Save button.
The Dimmer Readback value flashes.
Step 6: Press the Right button twice to move to the next
field.
The LCD Backlight value flashes.
Step 7: Press the Up and Down buttons to change the
value.
“L” means the LCD BackLight Dimming Feature is ON.
“l” means the LCD BackLight Dimming Feature is OFF.
Step 8: Press the Left and Right buttons to select the
next Flag
or proceed to the next step until you do not want to make
any more changes to the remaining FLAGS.
MENU
MISC. SETTINGS?
