• Scenes (including fade rates)
• Scene Labels
• Remote To ID numbers (unless already at zero (0))
• Assign Zones
• Exclusions
• Zones
• Zone Labels
To set the personality:
Step 1: Access the Programming and Configuration Level menu.
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up and Down buttons until SET
PERSONALITY? flashes on the LCD display.
Step 4: Press the Select/Save button.
The current Personality number flashes.
Step 5: Press the Up and Down buttons to change the
value.
Step 6: Press the Select/Save button to save the value.
Step 7: SET PERSONALITY? flashes again.
Step 8: Press Menu/Cancel to exit the menu.
Testing the Stations
Test each station by raising and lowering each zone that is assigned
to a dimmer. Check to see that control of the dimmer cabinet or other
control device is correct and smooth.
Main Level Menus
MENU
SET PERSONALITY?
To Next Page
