Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 39 of 80
indicators no longer are lit. Pressing of the Page Zones
button toggles the pages.
Step 4: 24 Zones: “P1-P4” is displayed by the top right 2
characters, indicating zones 1 to 8, 9 to 16, 17-24 or 25-
32 are being displayed. When you reach “P3 or P4” the
Zone number indicators no longer are lit. Pressing of the
Page Zones button toggles the pages.
To Set the Max Number of Zones:
Step 1: Access the Programming and Configuration Level menu.
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up or Down buttons until
MISC.SETTINGS? flashes on the display.
Step 4: Use the Select/Save button to select the menu.
The current submenu flashes.
Step 5: Press the Up or Down buttons to scan through
the submenus.
Step 6: Press the Select/Save button on MAX ZONES=XX?
Step 7: Press the Up or Down buttons to set the scroll
throughout the options.
Step 8: Press the Select/Save button to save the settings.
Step 9: Press Menu/Cancel to exit the menu.
Personalities
You can set up various personalities that include different preset
Scenes. For example, a church could use one set of eight preset
Scenes for Sunday church service, and a different set of eight preset
Scenes for evening choir performances. By choosing Personality 02,
the second (choir performance) set of Scenes could be recorded
without disturbing the normal Sunday church service settings.
The following information will need to be re-entered for each
personality:
MISC. SETTINGS:
FLAGS=rblto - - -
