Leviton D4200 - Programming and Configuration Level Flowchart

User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 21 of 80
Figure 10 - LCD Screen Shots of Programming and
Configuration Level Menu’s
Programming and
Configuration Level Menus
MENU
SET PERSONALITY
MENU
EDIT NETWORK
MENU
MISC SETTINGS
MENU
ASSIGN ZONES
ASSIGN ZONES:
Z01:CIRCUIT=0001
ASSIGN ZONES:
START CHANN=0001
ID=000
NET MASTER
PERSONALITY: 01
MISC. SETTINGS:
FLAGS=r b l t o i -
MISC. SETTINGS:
SETUP ASTROTIME?
MISC. SETTINGS:
LATTITUDE=00
MISC. SETTINGS:
SUNRISE=00:00
MISC. SETTINGS:
SUNSET=00:00
MISC. SETTINGS:
WEEK=XX
MISC. SETTINGS:
MIDNIGHT=12:00
MISC. SETTINGS:
SR=06:04SS=17:56
MISC. SETTINGS:
MAX ZONES=32
ID=000
REMOTE TO=000
