Individual Lighting Levels
Open the cover to access the lighting level buttons. Using the Zone
Up and Down buttons, adjust the individual lighting levels for
each of the 8/16/24/32 possible Zones. The approximate lighting
level for each Zone is represented by the Zone level LED indicators.
The exact percentage for each Zone is shown on the LCD display.
There is an indicator (P1 or P2 or P3 or P4) in the upper
right corner of the display to inform you what page of
zones you are currently in. Press the Page Zones button
to alternate the Zone numbers between P1 (1-8) P2 (9-
16), P3 (17-24) and P4 (25-32). When in P3 or P4 the
Zones LED indicators will not light)
• To increase or decrease a Zone lighting level by one percent,
momentarily press any Zone Up or Down button.
• To rapidly increase or decrease a Zone lighting level, press and
hold the button.
The lighted Scene buttons go dark and the LCD display
shows MANUAL MODE after any Zone Up or Down
button is pressed. You can record these new values for
the Scene if you prefer the new lighting levels.
