User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 45 of 80
Step 7: For the following types, Scene, Max and OFF, you must
also set a delay time. Press the Left and Right
buttons to highlight a Delay time.
Step 8: Press the Up and Down buttons to change the
value.
Step 9: Press Select/Save to save the value.
Step 10: Repeat Steps 4-9 for each Sequence you wish to
program.
Step 11: Press the Menu/Cancel button to exit this menu.
The “SKIP” control command is a way to insert a “place
holder” or “no operation” when you want to temporarily
exclude some other scene or control command... then
put it back at a later time.
Enabling the Sequencer
This function globally enables or disables the sequencer.
To enable or disable the sequencer:
Step 1: Press the Menu/Cancel button.
Step 2: Press the Up and Down buttons until
SEQUENCER= flashes on the LCD display.
Step 3: Press the Select/Save button.
The
OFF
or
ON
value flashes.
Step 4: Press the Up and Down buttons to change the
value.
Note: Press
Clear
to change the value to
OFF
.
Step 5: Press the Select/Save button to save the value.
Step 6: Press the Menu/Cancel button to exit this menu.
Zone Labels: Naming a Scene or Zone
You can program alphanumeric labels with up to 14 characters for
any Scene MAX, OFF or Zone ID buttons.
To name a Scene or a Zone:
