User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 38 of 80
Step 12: Press the Select/Save button to save the value.
The LCD display shows
SUNSET=
with the hour field
flashing.
go to www.srrb.noaa.gov/highlights/sunrise/sunrise.htm
for a complete listing of Sunrise and Sunset times for
your location
Step 13: Press the Up and Down buttons to set the
sunset hour.
Step 14: Press the Right button to move to the minute
field.The minute value flashes.
Step 15: Press the Up and Down buttons to set the
minutes.
Step 16: Press the Select/Save button to save the settings.
Step 17: Press Menu/Cancel to exit the menu.
3 - Setting Max. Number of Zones -
MANDATORY
This menu allows the installer/administrator to set the maximum
number of zones to either 8, 16, 24, or 32 zones. The Page Zones
button and other menus and features will be limited to this
restriction.
Default setting: 16
When the maximum number of Zones is set to:
Step 1: 8 Zones: No Page information shown. Pressing the Page
Zones button has no effect.
Step 2: 16 Zones: No Page information displayed. Pressing the
Page Zones button toggles between showing zones 1 to
8 or 9 to 16.
Step 3: 24 Zones: “P1-P3” is displayed by the top right 2
characters, indicating zones 1 to 8, 9 to 16 or 17-24 are
being displayed. When you reach “P3” the Zone number
ASTRO TIME SETUP
COMPLETED!
