User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 37 of 80
time of sunrise and sunset (often found in the daily newspaper). Visit
www.srrb.noaa.gov/highlights/sunrise/sunrise.html
for a complete listing of
Latitude, Longitude, Sunrise and Sunset information.
Step 1: Access the Programming and Configuration Level menu.
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up or Down buttons until
MISC.SETTINGS? flashes on the display.
Step 4: Use the Select/Save button to select the menu.
The current submenu flashes.
Step 5: Press the Up or Down buttons to scan through
the submenus.
Step 6: Press the Select/Save button on SETUP ASTROTIME?
Step 7: Press the Up or Down buttons to set the
LATTITUDE.
See Appendix for Latitude information for your location
Step 8: Press the Select/Save button to save the value.
The LCD display shows SUNRISE= with the hour field
flashing.
go to www.srrb.noaa.gov/highlights/sunrise/sunrise.htm
for a complete listing of Sunrise and Sunset times for
your location
Step 9: Press the Up and Down buttons to set the
sunrise hour.
Step 10: Press the Right button to move to the minute field.
The minute value flashes.
Step 11: Press the Up and Down buttons to set the
minutes.
MISC. SETTINGS:
FLAGS=rblto - - -
MISC. SETTINGS:
SETUP ASTROTIME
?
