User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 17 of 80
Power Up the Unit
The default network ID is set to 000. When the station is reset or
powered on and the network ID is zero, the LCD will prompt you for a
valid network ID.
Upon initial power up you should see the following menu with the ID
flashing:
You must enter a valid network ID to get to the main menu.
To set the master station ID number:
Step 1: Press the Up and Down buttons to change the
value. See Figure 11 for the location of the buttons.
Note: You need to set a unique number from 001 to 127 for it
to function.
Step 2: Press the Select/Save button to save the values.
ID=000
NET MASTER
MANUAL MODE
M18 MON 12:00P
MAIN MENU
