Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 47 of 80
Step 8: Select another Zone or Scene to edit,
or press the Menu/Cancel button twice to exit this
menu.
Editing Zone Excludes
This menu allows the installer to edit which zones are not to be
included in recorded preset/scenes. This menu is “record” locked.
To Exclude a zone from a Scene:
Step 1: Press the Menu/Cancel button.
Step 2: Press the Up and Down buttons until EDIT
EXCLUDES? flashes on the LCD display.
Step 3: Press the Select/Save button. The LCD changes to:
Step 4: Choose a preset scene from preset/scene buttons, remote
presets; IR or Entry Station. The LCD changes to
(assuming you pressed the preset scene 1):
Step 5: Press the Zone Up to exclude a zone and the Zone
Down button to
include a zone. When you press a
Zone Up button, the corresponding“-” changes to a
digit which represents the least significant
digit of the
affected zone’s ID (Example: Zone 16 is represented by 6,
25 is represented by a 5). Alternately, when you press a
Zone Down button the “
digit ” returns to a dash (“-”)
meaning the zone is
included .
6: Use Page Zones button to select up to 4 pages of zones. Page
1 is zones 1 to 8, page 2 is zones 9 to 16, page 3 is zones 17 to
24, page 4 is zones 25 to 32.
Use Clear to clear all “excludes” i.e. to include all zones. By
default all zones are included.
EXCLUDE: SELECT
A SCENE TO EDIT
SCENE 01
M01 - - - - - - - - P01
