Overriding a Lock
If the control station is locked by a code number, the LCD displays
ENTER CODE when a locked operation is attempted.
To override a lock:
1: Press the Up and Down buttons to enter the
programmed code number (000-999).
Press
Clear
to begin entering numbering from zero (0).
Shortcut: Use a code number between 000 and 999, as
the Preset - Scene buttons 1 to 8 and MAX (9) and OFF
(0) can be used to enter the code in directly.
Note:
Step 2: Press the Select/Save button to enter the value.
The originally selected operation begins and the unit
remains unlocked for approximately 5 minutes.
The PIN 6 key lock input on the Luma-Net connector
always locks the station overriding the station lock and
there is no “Pass Code” to override this lock.
Congratulations:
Your D4200 LCD Station is completely set up and ready for use.
