Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 24 of 80
The Zone number LED’s do not light up on P3 or P4
Programming and Configuration Level
Menu
For the installation programming, you must use the Programming and
Configuration Level menus along with the main level menus.
These features include:
• Assigning Zones
• Editing the Network
• Setting Personality
• Miscellaneous settings, including the
• Flags:
• Dimmer Readback,
• Double Bump,
• LCD Backlight Time Out
• Time Master
• Previous Code Compatibility and
• IR Control.
• Astronomical Time Clock Setup (sunrise, sunset, latitude) and
• Maximum Number of Zones
To access the Programming and Configuration Level menu:
Step 1: Press and hold the Menu/Cancel button for 10 seconds,
until LEVITON appears on the LCD display.
Step 2: Immediately release the Menu/Cancel button.
Step 3: Press and hold the Zone 4 Down button for at least 10
seconds, until LEVITON disappears from the LCD display.
Step 4: Press the Menu button to access the Advanced features
that have been added to the menu.
When you are finished using the Setup menu selections,
be sure to return to the regular menu.
