User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 29 of 80
Step 5: Press the Select/Save button to select ZONE or START
CHANN.
The selected item flashes.
Step 6: Press the Up and Down buttons to change the
value.
Note: Press
Clear
to set the value to
NONE
.
HELPFUL HINT: Press
the Preset/Scenes 1 to 8 and Max/
Off to generate the digits 1 to 8, 9 and 0 (zero).
Step 7: Press the Select/Save button to save the zone
assignment.
Step 8: Repeat steps 4-7 for the remainder of the zones you wish
to assign.
Step 9: Press Menu/Cancel to exit the menu.
MISC. SETTINGS MENU
This menu has three categories of sub-menus.
1: FLAGS.
1.1 Dimmer Readback
1.2 Double Bump
1.3 LCD Display
1.4 Time Master
1.5 Old Code Compatibility
1.6 IR Control
2: Set Up Astro Time.
Latitude
Sunrise
Sunset
Display of the current Week Number
Display of the calculated midnight
Display of the current Sunrise and Sunset Time.
3: Maximum Zones.
1. FLAGS Menu
The following list of individually setable option flags. Use
UPPER
case
to indicate the feature is ON, and use “
lower
” case to indicate the
feature is OFF. By default these options are all OFF (lower case)
