Step 8: Press the Left and Right buttons to select the
next Flag
or proceed to the next step until you do not want to make
any more changes to the remaining FLAGS.
Step 9: Press the Select/Save button to record the new setting.
Step 10: Exit the Programming and Configuration Level menu.
1.5 - Previous Code Compatibility
This flag allows this D4200 station to work with units that have
previous code installed on them. This usually occurs when a LCD
station is upgraded to new code, but the entry stations are not. For
installs where only the 2.xx code resides, you want to make sure that
the flag is set to the “o”.
To enable this feature:
Step 1: Access the Programming and Configuration Level menu.
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up and Down buttons until MISC.
SETTINGS? flashes on the LCD display.
Step 4: Press the Select/Save button.
FLAGS
flashes on the LCD display.
Step 5: Press the Select/Save button.
The Dimmer Readback value flashes.
Step 6: Press the Right button four times to move to the
next field.
The Previous Code Compatibility value flashes.
Step 7: Press the Up and Down buttons to change the
value.
“O” means the Previous Code Feature is ON (for use when
units still have 1.xx code).
“o” means the Previous Code Feature is OFF.
Step 8: Press the Left and Right buttons to select the
next Flag
or proceed to the next step if you do not want to make
any more changes to the remaining FLAGS.
Step 9: Press the Select/Save button to record the new setting.
Step 10: Exit the Programming and Configuration Level menu.
