User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 42 of 80
Step 7: Press the Right button to move to the next field.
Step 8: The MINUTES field flashes.
Step 9: Press the Up and Down buttons to change the
value.
Note: Press
Clear
to return the value to
00
.
Step 10: Press the Right button to move to the next field.
The Scene field flashes. Note “NONE” appears as default.
Step 11: Press the Up and Down buttons to select a
Scene or one of the following choices:
• None
• Seq. Step - Starts a Sequence at a particular step
• Cell ON - Turns the Photocell option on at the a-2000D dimmer
rack
• Resume - Resumes the Sequencer
• Seq OFF - Turns the Sequencer Off
• Seq ON - Turns the Sequencer Om
• OFF - Applies the OFF button
• MAX - Applies the MAX button
• Scene - Applies a Scene
Note: Press
Clear
to return the value to
NONE
. Erasing a
Scene effectively erases the Event.
Step 12: Press the Right button to move to the next field.
The first value in the
SMTWTFS
(Days of week) field
flashes.
Step 13: Press the Up and Down buttons to change the
value. When a dash replaces a day of the week, it
becomes inactive.
Note: Press Clear to change the values to
- - - - - -
-
(inactive).
Step 14: Press the Right button to move to the next field.
and use the Up and Down buttons to change
the value.
Repeat this process for all 7 days.
Step 15: Press the Select/Save button to save these values for
the Event.
The Event number flashes again.
