User Guide
Leviton D4200 LCD Ver 2.0 Architectural Lighting Controller Page 26 of 80
Master stations and remote “Entry” stations used in the
same room must be linked and their numbers bonded
together so that the master station responds to the
correct remote station. Once this is done, they must be
installed in the same room or space. If the remote station
is mounted in another room, it will still select preset
Scenes in the master station that it is bonded to in the
wrong room.
The master station and the remote stations mated to it must each
have a different ID number. The remote station's target or remote to
ID number must be mated to the master station's ID number to
function properly in normal operation.
To set the master station ID number:
Step 1: Access the Programming and Configuration Level menu
Step 2: Press the Menu/Cancel button.
Step 3: Press the Up or Down buttons until EDIT
NETWORK? flashes on the LCD display.
Step 4: Press the Select/Save button to select the master station
ID number.
The Network ID number flashes.
Step 5: Press the Up and Down buttons to change the
value.
You need to set a unique number from 001 to 127 for it
to function.
MENU
EDIT NETWORK
