Lexmark 4036-307 - Page 117

Connector locations 5-11
4036-307, -308
J6 1 LOOP_IN
2 +24 VM
3 +24VM
4 XDATAP0
5GND
6 XDATAP1
7GND
8 XDATAP2
9GND
10 XDATAP3
11 GND
12 XDATAP4
13 GND
14 GND
15 XDATAP5
16 GND
17 XDATAP6
18 GND
19 XDATAP7
20 GND
21 /AM_RD1
22 /AM_RD2
23 /PAPER_OUT
24 /AM_WRI
25 AMCLK
26 LOOP_OUT
J8 1 FAN_FEEDBACK2
2GND
3 FAN_POWER
J11 1 +5 V_SENSOR
2GND
3 FB_COVER_OPEN
A1 Board
Conn-
ector
Pin
no.
Signal
