Lexmark 4036-307 - LCD HV Inverter Board Removal

4-26 Service Manual
4036-307, -308
LCD HV inverter board removal
1. Remove the control panel assembly. See “Control panel assembly removal” on page 4-24.
2. Remove the two screws (A) and lift the metal cover.
3. Remove the four screws (B) and disconnect the two cables (C).
A
BCC
