Lexmark 4036-307 - Flatbed Cover with Glass Removal

4-28 Service Manual
4036-307, -308
Flatbed cover with glass removal
1. Remove the control panel assembly. See “Control panel assembly removal” on page 4-24.
2. Remove the two screws (A) and two screws (B).
3. Lift straight up to remove the upper housing.
ABA
