Lexmark 4036-307 - Flatbed CCD Optical Unit; ADF Optical Unit; Document Input Tray Removal

Repair information 4-3
4036-307, -308
Flatbed CCD optical unit
ADF optical unit
Document input tray removal
1. Press down on the latches (A) on the top of the document input tray, and tilt the document tray back.
2. Disconnect the paper length connect cable (B).
3. Press the tabs (C) on the side to release the document input tray from the ADF.
Do not loosen
Do not loosen
C A B A
