3-4 Service Manual
4036-307, -308
Clear Log
Use Clear Log to remove the current information in the Event Log. This affects both the viewed log and the
printed log information.
1. Touch to select Clear Log from the Event Log menu.
2. Touch to select Yes to clear the Event Log, or touch to select NO to exit the Clear Log menu. If
YES is selected, Deleting EVENT LOG displays on the screen.
SCANNER TESTS
ASIC Test
A pattern appears, and ASIC Test Passed displays. If xxxxxx displays, the test was unsuccessful.
Press Stop (
) to return to the SCANNER TESTS menu.
Feed Test
To run the Scanner Feed test:
1. Touch to select Feed Test from the SCANNER TESTS menu.
2. The panel displays the setting's current value [setting's current value] . Use the arrows to select from
Letter, Legal, or A4.
3. Touch START to begin.
Feed Test Testing… displays.
4. Touch Back to return to the Diagnostics Menu.
Scanner Manual Registration
1.
Touch to select Scanner Manual Registration from SCANNER TESTS.
2. The panel displays the setting's current value [setting's current value] . Use the arrows to select the
new value. The following settings are listed:
3. Touch Submit to make the changes.
Scanner Manual Registration
FB Left Margin
FB Top Margin
ADF Front Left Margin
ADF Front Top Margin
0
0
0
0
ADF Rear Left Margin 0
ADF Rear Top Margin 0
Back
Submit
