Diagnostic information 2-29
4036-307, -308
Information on LCD touch-screen buttons
Button Button name Function or description
Down arrow Touch the down arrow to move down to the next item in a list, such as a list of
menu items or values. The down arrow does not appear on a screen with a short
listing. It only appears if the entire listing cannot be seen on one screen. On the
last screen of the listing, the down arrow is gray to indicate that it is not active
since the end of the list appears on this screen.
Up arrow Touch the up arrow to move up to the next item in a list, such as a list of menu
items or values. When on the first screen presented with a long list, the up arrow is
gray to indicate that it is not active. On the second screen, which is needed to
show the rest of the listed items, the up arrow is blue to show that it is active.
Unselected radio
button
This is an unselected radio button.
Selected radio
button
This is a selected radio button. Touch a radio button to select it. The radio button
changes color to show that it is selected. In Sample screen two, the only paper
size selected is Letter.
Cancel Job See “Cancel Jobs” on page 2-26.
Cancel
Job
